Feature:

1. Double up the power capacity, thinner, lighter, Brand new ISDT Q6 Plus with rounded edge design easily stows in bag or pocket. Same size as the SC-608 charger with twice the power capacity.

2. 2.4″ IPS Display, up to 178° visible angle,auto-brightness screen, still visible under strong sunlight.

3. Highly optimized internal construction with higher cooling efficiency. Higher speed and efficiency synchronous Digital Power Supply Technology. High speed ball-bearing fan promotes active cooling increase by 300%, even though the size has been reduced by 50%.

4. Outstanding performance from every perspective ARM 32bit high speed Processor.

5. Instant boot (within seconds) when initialized After the depth of optimizationscOs，Instant Boot, only a few seconds.

6. One key shuttle control, One key metal shuttle control replaces the multi-button press operation, makes charging with the Q6 a delightful experience.

7. scOsSpecially designed for smart charging OS Bright, colorful, easy access set-up and status display. 80% deduction of operation process. Firmware updates can be performed using a personal computer.

8.Multiple Languages, Comes in a variety of languages to suit your needs.


Specification:

Input Voltage: DC 7-32V

Maximum input current: 15A

Output Voltage: 0-30V BattGo Support smart battery: Output support

Charge Current: 0.1A-14.0A

Discharge Current: 0.1- 3.0A

Max Charge Capacity: 300W

Max Discharge Capacity: 8W

Balance Current：10A/cell

Balance Cells: 2-6s

Color: Multi-color cover

Supported Battery Type:LiFe/Lilon/LiPo/LiHv(1-6S) NiMH/Cd (1-16S) Pb (1-12S)

Display: 2.4〃320×240 IPS LCD

Operating Temperature: 0-40°C

Storage Temperature: -20-60°C

Dimensions: 80x80x33.5 mm

Weight: 119g


Packing included:

1x ISDT Q6 Pro BattGo Charger

1x Manual
